DG30/170 P Drilling machine
| Power [W]: | 300 |
|---|---|
| Speed: | 1700 / min |
| Construction form: | Pistol |
| Current: | Pneumatic |
Product number:
42114000
Ölfreier Betrieb möglich
DG30/170 P Drilling machine
Applications
Pneumatic drilling machines, pistol form, used in any type of industrial company as well as in workshops and for maintenance.
Air drill - gun shape for horizontal drilling operation
Reliable pneumatic drilling machine with excellent power to weight ratioChangeable chucks available for different applications
The pneumatic drilling machines are starting at low speed to facilitate initial insertion of the bit
Long tool life at high power
The pistol form of the air powered drilling tools are ideal for horizontal drilling operations.
| Power [W]: | 300 |
|---|---|
| Speed: | 1700 / min |
| Clamping Range Ø: | 1 - 10 mm |
| Construction form: | Pistol |
| Start: | Taster |
| Direction of rotation: | Rechts |
| Weight [kg]: | 1.18 |
| Housing Ø: | 38 mm |
| Length [mm]: | 233 |
| Height: | 155 mm |
| Recommended hose Ø: | 9 mm |
| Air consumption: | 9 l/s |
| Sound pressure level: | 77 dB(A) |
| Current: | Pneumatic |
| Working pressure: | 6.3 bar |
| Chuck: | Self-locking chuck (3/8" x 24 UNF) |
| Inlet air connection: | G 1/4" |
| Vibration: | < 2.5 m/s² |
