DW30/340-SP Angle drilling machine
| Power [W]: | 300 |
|---|---|
| Speed: | 3400 / min |
| Chuck: | Collet chuck ER11 |
| Current: | Pneumatic |
Product number:
44104100
Ölfreier Betrieb möglich
DW30/340-SP Angle drilling machine
Applications
Pneumatic angle drilling machine for work in hard-to-reach places. The angle drilling machine is used in all industrial areas as well as workshops and plant repairs.
Air angle drilling machine with collet chuck - professional tool for the industry
Reliable pneumatic drilling machine with excellent power to weight ratio.Small head dimension allows working in narrow spaces.
Special chuck for pneumatic tools and high-precise collet chucks provide efficient use.
Long tool life at high power.
The angle drilling machine has a 90 degree angle head, suitable for your application.
| Power [W]: | 300 |
|---|---|
| Speed: | 3400 / min |
| Chuck: | Collet chuck ER11 |
| Clamping Range Ø: | 1 - 7 mm |
| Start: | Valve lever |
| Direction of rotation: | Rechts |
| Weight [kg]: | 1.0 |
| Housing Ø: | 40 mm |
| Length [mm]: | 255 |
| Height: | 54 mm |
| Recommended hose Ø: | 9 mm |
| Air consumption: | 9 l/s |
| Sound pressure level: | 76 dB(A) |
| Current: | Pneumatic |
| Working pressure: | 6.3 bar |
| Construction form: | 90° angle head |
| Inlet air connection: | G 1/4" |
| Vibration: | < 2.5 m/s² |
Collet is not included in scope of delivery!
