K16/7-FG Hexagonal-crimping-die
| Shape: | Spring large (FG) |
|---|---|
| Crimping contour: | Sechskant nach DIN 48083 |
| Index: | 16 |
| Crimping width: | 7 mm |
Product number:
76900343
Spring clip press inserts
K16/7-FG Hexagonal-crimping-die
Applications
K16: 70 mm2 copper non tension and full tension, as well as 50 mm2 aluminium non tension and full tension. 50/8 mm2 Al-sleeve (ACSR).
| Shape: | Spring large (FG) |
|---|---|
| Suitable for: | crimping cable lugs, connectors, Al-sleeves |
| Crimping contour: | Sechskant nach DIN 48083 |
| Index: | 16 |
| Crimping width: | 7 mm |
