PH120-A Hydraulic cutting head
| Cutting force: | 100 kN |
|---|---|
| Opening width: | 120 mm |
| Hydraulic connection: | Nippel CEJN Serie 115 |
Product number:
72552300
Safe design
PH120-A Hydraulic cutting head
Applications
The PH120-A is a powerful 100kN hydraulic cutting head for connecting to a separate pump.
The cutting head is designed for cutting cable of up to 120 mm diameter and is ideally for providers, utility companies and their service providers, power plants and telecommunications.
Particularly robust and low-maintenance design with powerful 100kN.
The hydraulic cutting head is particularly suited for telephone and electric cables but it also cuts grounding cables with steel tape armor.
The pin retainer closes the cutting head securely.
The cutting head can be combined with usual hydraulic pumps.
Technical specifications
The hydraulic cutting head is particularly suited for telephone and electric cables but it also cuts grounding cables with steel tape armor.
The pin retainer closes the cutting head securely.
The cutting head can be combined with usual hydraulic pumps.
| Cutting force: | 100 kN |
|---|---|
| Opening width: | 120 mm |
| Weight: | 9.6 kg |
| Length [mm]: | 570 |
| Working pressure: | 700 bar |
| Hydraulic connection: | Nippel CEJN Serie 115 |
| Lock type: | Bolt safety |
| Head: | closed |
